Add Feature to Selection

Add the currently highlighted reference model feature to the Selection window. If other features are already selected, the feature will be added to the current selection rather than replacing it as is done when clicking features. See Select Active Model Feature for more information.

Delete Feature

Remove the currently highlighted feature from the reference model. See Delete Feature for more information.

Delete Sub-Tree

Remove a reference model feature sub-tree, containing one or more features, from the reference model. See Delete Sub-Tree for more information.

Create New Point

Digitize a new reference model point. See New Point By Digitizing for more information.

Create New Alignment

Digitize a new reference model alignment. See New Alignment By Digitizing for more information.

Create New Cross-section

Create a new cross-section for the reference mdoel. See New Cross-section for more information.

Create New Surface

Digitize a new reference model surface. See New Surface By Digitizing for more information.

Create New Vertical Surface

Digitize a new vertical surface in the reference model. See New Vertical Surface for more information.

Create New Supersurface

Create a new supersurface from existing reference model surfaces. See New Supersurface for more information.

Create New Template

Create a new reference model template using an existing cross-section. See New Template from a Cross-Section for more information.

Create New Line

Create a new reference model line using existing reference model points. See New Line from Existing Points for more information.

Create New Profile

Create a new reference model profile using existing reference model points. See New Profile for more information.

Create New Station Catalogue

Create a new station catalogue in the reference model. See New Station Catalogue for more information.
